제품 규격 및 구성사양

Output Mode		Independent, Tracking, Parallel, Series
Output Voltage/Current		Independent　　0~20V Dual　　0~1A Dual (CPS-201T) 　　　　　　　　0~30V Dual　　0~3A Dual (CPS-303T), 0~5A Dual (CPS-305T)
		Tracking　　0~±20V　　0~±1A (CPS-201T) 　　　　　　0~±30V　　0~±3A (CPS-303T), 0~±5A (CPS-305T)
		Parallel　　0~20V　　0~2A (CPS-201T) 　　　　　0~30V　　0~6A (CPS-303T), 0~10A (CPS-305T)
		Series　　0~40V　　0~2A (CPS-201T) 　　　　　0~60V　　0~3A (CPS-303T), 0~5A (CPS-305T)
		Fixed Output　　5V 2A (CPS-303T, CPS-305T only)
Ripple Rejection		≤2mVrms (5Hz~1MHz)
Regulation	Line / Load	Less than 0.01%+3mV / Less than 0.02%+5mV
Resolution	Voltage / Current	0.1V Digital Volt Meter / 0.01A Digital Ampere Meter
Instant Return Time		100㎲(50% Load Changing)
Display	Voltage	3 Digital Volt Meter, CV Indicate LED
	Current	3 Digital Ampere Meter, CC Indicate LED
Protection		Over Voltage, Over Load(Limit)
Fixed output	Voltage/Current	5 Volt / 2 Ampere (CPS-303T, CPS-305T only)
	Line Regulation	Under 5mV
	Load Regulation	Under 10mV
	Ripple Noise	≤2mVrms
	Voltage Accuracy	5V±0.25V

STANDARD ACCESSORIES
• AC power cord : 1ea
• Output cable : 2ea
• User’s guide manual : 1ea
